CITEL 1PHASE TYPE2 COMPACT SPD IMAX 40KA 230/400 TT-TN

Stock Code: DS240S-230/G

Descriptions

• Compact single-phase Type 2

• Ideal for Domestic Installations

• In : 20 kA

• Imax : 40 kA

• Pluggable module

• Remote signaling contact (option)

• Complies with EN 61643-11 and IEC 61643-11

• UL1449 ed.4

Specifications

Type	Compact Single Phase Type 2 surge protector
Number of Protected Poles	Single Phase
Connection Mode	L/N or L/PE
Max. AC Operating Voltage	255VAC
AC System	TT-TN
Nominal Discharge Current - In	20kA
Max. Discharge Current - by pole Imax	40kA
Protection Level	1.25kV
Temporary Over Voltage (TOV) - 5 sec.	335VAC Withstand
Remote Signal	Yes
Features	Configuration CT2 (common and differential mode)
Network	230V Single Phase
ETIM Class	EC000941

Downloads

Click on any of the following links to download the file.

Datasheet (pdf)
