20/10 Amp - 1 Pole NO/NC Changeover 1 Form C

20/10 Amp - 1 Pole NO/NC Changeover 1 Form C



    • 20A switching capability



    • Ambient temp -40C to +125C



    • Standard and Sensitive coils



    • PCB terminals available



    • 1 Form C



    • Sealed IP67 & Dust protected also available



    • Contact gap >0.6mm



    • Contact materials AgSnO2



    • RoHS & ELV compliant


Code Description Maximum Rated Switching Current Contact Arrangement Coil Voltage Pick Up Max VDC Drop Out Max VDC Max VDC Coil ? ? 10% Coil Power Price
HFV6012ZSLT HONGFA AUTOMOTIVE RELAY 12DC 20A 1CO HFV6/012-ZSLT 20AMP 1C - Single Pole Changeover 12VDC 7.2 1.2 23?C - 25 / 85?C - 19 124 x (1?10%) 1.2W
HFV6024ZSLT HONGFA AUTOMOTIVE RELAY 24DC 20A 1CO HFV6/024-ZSLT 20AMP 1C - Single Pole Changeover 24VDC 14.4 2.4 23?C - 47 / 85?C - 35 441 x (1?10%) 1.3W
HFV6012ZSTD HONGFA AUTOMOTIVE RELAY 12DC 20A 1CO HFV6/012-ZSTD - - - - - - - -
