2 Coil Latching 200mW 2 Amp

2 Coil Latching 200mW 2 Amp

  • 0.5A 125VAC/3A 300VDC contact rating
  • 2 pole c/o contacts
  • 2 Coil latching version
  • Standard & Sensitive coil version
  • Fully sealed
  • Bifurcated contacts
  • Contact Material AgSnO2, other types available upon request
  • Dielectric strength 2KV between coil & contacts
  • Also available 3Kv version Dielectric ie HFD3-V
  • Surface mount versions available
  • Surge withstand voltage up to 2500VAC meets FCC Part 68 and Telecordia
  • RoHS Compliant
  • Tape packing reel information available with SMT versions
  • Meets EN60950/EN41003
  • Approvals UL/CSA & VDE


Code Description Price
HFD3001.5L2 HONGFA PCB SIGNAL RELAY 1.5VDC 2A 2CO HFD3/1.5-L2
HFD3003L2 HONGFA PCB SIGNAL RELAY 3VDC 2A 2CO HFD3/3-L2
HFD3004.5L2 HONGFA PCB SIGNAL RELAY 4.5VDC 2A 2CO HFD3/4.5-L2
HFD3005L2 HONGFA PCB SIGNAL RELAY 5VDC 2A 2CO HFD3/5-L2
HFD3006L2 HONGFA PCB SIGNAL RELAY 6VDC 2A 2CO HFD3/6-L2
HFD3009L2 HONGFA PCB SIGNAL RELAY 9VDC 2A 2CO HFD3/9-L2
HFD3012L2 HONGFA PCB SIGNAL RELAY 12VDC 2A 2CO HFD3/12-L2
HFD3024L2 HONGFA PCB SIGNAL RELAY 24VDC 2A 2CO HFD3/24-L2
