QC Terminals

QC Terminals



    • 40A switching capability



    • QC Terminal



    • 1 Form A contact



    • Dust protected & wa sk tight constructions



    • Contact material AgSnO2



    • AgNiO.15 contacts available



    • RoHS & ELVcompliant


Code Description Maximum Rated Switching Current Contact Arrangement Coil Voltage Pick Up Max VDC Drop Out Max VDC Max VDC Coil ? ? 10% Coil Power Price
HFV4-006-1H-1-G HONGFA AUTOMOTIVE RELAY 6VDC 40A NO HFV4/006-1H1G 40AMP 1A- Single Pole Normally Open 6VDC 3.9 0.6 23?C - 10.1 / 85?C - 7.9 22 x (1?10%) 1.6W
HFV4-012-1H-1-G HONGFA AUTOMOTIVE RELAY 12DC 40A NO HFV4/012-1H1G 40AMP 1A- Single Pole Normally Open 12VDC 7.8 1.2 23?C - 20.2 / 85?C - 15.7 85 x (1?10%) 1.7W
HFV4-024-1H-1-G HONGFA AUTOMOTIVE RELAY 24DC 40A NO HFV4/024-1H1G 40AMP 1A- Single Pole Normally Open 24VDC 15.6 2.4 23?C - 40.5 / 85?C - 31.5 350 x (1?10%) 1.6W
