Double Coil Latching

Double Coil Latching



    • 200A contact switching capability



    • According to ANSI C 12.1



    • Switching power up to 55.4kVA



    • 4Kv dielectric strength between coil and contacts



    • RoHS compliant


Code Description Maximum Rated Switching Current Contact Arrangement Coil Voltage Pick Up Max VDC Coil ? ? 10% Coil Power Set/Reset Voltage VDC Max Price
HFE17A0122DT2 HONGFA LATCHING RELAY 12VDC 200A 2NC HFE12-A/012-2DT2 200AMP 2B - Single Pole Normally Closed 12VDC 9.6 6 + 6 x (1?10%) 24W 200
HFE17A0242DT2 HONGFA LATCHING RELAY 24VDC 200A 2NC HFE12-A/024-2DT2 200AMP 2B - Single Pole Normally Closed 24VDC 19.2 24 + 24 x (1?10%) 24W 200
HFE17A0482DT2 HONGFA LATCHING RELAY 48VDC 200A 2NC HFE12-A/048-2DT2 200AMP 2B - Single Pole Normally Closed 48VDC 38.4 95 + 95 x (1?10%) 24W 200
