12 Amp Single Pole

12 Amp Single Pole

  • Change Over Contacts
  • Supplied complete, Relay, LED, Socket, Ejector Clip and Identification Label
  • 1 Part Number for simple ordering
  • AC & DC Coils
  • Supply status LED as standard
  • 35mm Din Rail mounting
  • 2 Socket types for ease of installation
  • 12A version
  • Other Coil Voltages available on request


Code Description Cable Size, Solid (mm2) Retainer Clip Module Type Socket Type Relay Voltage Relay Type Coil Voltage Contact Arrangement Maximum Rated Switching Current Dimensions (mm) Cable Size, Flexible (mm2) Approvals Operating Temperature Price
1RM-12 HONGFA RELAY INTERFACE MODULE 1CO 12VDC 1 x 4/ 2 x 2.5 14F-ERC-1 HF-EL 14FF-1Z-C2 12VDC HF115F0121ZS1AF 12VDC 1C - Single Pole Changeover 12AMP 52 x 75 x 15.8 1 x 4/ 2 x 2.5 CE, UL -40 to +85?C
1RM-24 HONGFA RELAY INTERFACE MODULE 1CO 24VDC 1 x 4/ 2 x 2.5 14F-ERC-1 HF-EL 14FF-1Z-C2 24VDC HF115F0241ZS1AF 24VDC 1C - Single Pole Changeover 12AMP 52 x 75 x 15.8 1 x 4/ 2 x 2.5 CE, UL -40 to +85?C
1RM-24A HONGFA RELAY INTERFACE MODULE 1CO 24VAC 1 x 4/ 2 x 2.5 14F-ERC-1 HF-EL 14FF-1Z-C2 24VAC HF115FA0241ZS1AF 24VAC 1C - Single Pole Changeover 12AMP 52 x 75 x 15.8 1 x 4/ 2 x 2.5 CE, UL -40 to +85?C
1RM-110A HONGFA RELAY INTERFACE MODULE 1CO 110VAC 1 x 4/ 2 x 2.5 14F-ERC-1 HF-EN 14FF-1Z-C2 110VAC HF115FA1151ZS1AF 110VAC 1C - Single Pole Changeover 12AMP 52 x 75 x 15.8 1 x 4/ 2 x 2.5 CE, UL -40 to +85?C
1RM-240A HONGFA RELAY INTERFACE MODULE 1CO 240VAC 1 x 4/ 2 x 2.5 14F-ERC-1 HF-EN 14FF-1Z-C2 230VAC HF115FA2301ZS1AF 230VAC 1C - Single Pole Changeover 12AMP 52 x 75 x 15.8 1 x 4/ 2 x 2.5 CE, UL -40 to +85?C
