ML25-S Single Deck PCB Terminal Blocks

ML25-S Single Deck PCB Terminal Blocks

  • 10mm Pitch PCB Terminal Block
  • 2 Pole Mono-block
  • 16 Amp Current rating
  • Moulded in Green UL94-V0 flame retardant PA
  • Rising Clamp Terminal
  • Captive screws
  • Guided pin alignment
  • ImQ and UL approved
  • Alternative colours available upon request


Code Description Materials (Terminals) Cable Size, Solid (mm2) Cable Size, Flexible (mm2) Materials (Body) Poles Operating Temperature Amperage Pitch Colour Voltage Price
ML252-10-S EUROCLAMP PCB TERMINAL BLOCK ANGLED 16A 10mm 2 POLE LEFT Tin-plated copper alloy 4 2.5 PA - UL 94 V0 2 -40 to +130?C 17.5 AMP 10.00mm White 750V
